Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Widthofcut59.5inches(151cm)
Wheeltread
50.5inches(128cm)
Wheelbase
48.6inches(123cm)
Overalllength(w/baskets)98.0inches(249cm)
Overallwidth70.62inches(179cm)
Overallheight80.83inches(205cm)
NetWeightw/reels(11Blade)1535lb(696kg)
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesareavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
ThinkSafetyFirst
Pleasecarefullyreadallofthesafetyinstructionsand
symbolsinthesafetysection.Knowingthisinformation
couldhelpyouorbystandersavoidinjury.
Theuseofprotectiveequipment,suchasbutnotlimited
to,foreyes,ears,feet,andheadisrecommended.
CAUTION
Thismachineproducessoundlevelsinexcessof
85dBAattheoperator'searandcancausehearing
lossthroughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
CheckingtheEngineOil
Theengineisshippedwithoilinthecrankcase;
however,theoillevelmustbecheckedbeforeandafter
theengineisrststarted.
Crankcasecapacityisapproximately3.9quarts(3.7l)
withthelter.
Usehigh-qualityengineoilthatmeetsthefollowing
specications:
•APIClassicationLevelRequired:CH–4,CI–4or
higher.
•Preferredoil:SAE10W–30
•Alternateoil:SAE15W–40
ToroPremiumEngineoilisavailablefromyour
distributorinthe10W–30viscosity.Seetheparts
catalogforpartnumbers.
Note:Thebesttimetochecktheengineoiliswhenthe
engineiscoolbeforeithasbeenstartedfortheday.If
ithasalreadybeenrun,allowtheoiltodrainbackdown
tothesumpforatleast10minutesbeforechecking.
Iftheoillevelisatorbelowthe“add”markonthe
dipstick,addoiltobringtheoilleveltothe“full”mark.
DONOTOVERFILL.Iftheoillevelisbetweenthe
“full”and“add”marks,nooiladditionisrequired.
Important:Besuretokeeptheengineoillevel
betweentheupperandlowerlimitsontheoil
gauge.Enginefailuremayoccurasaresultofover
llingorunderllingtheengineoil.
1.Positionthemachineonalevelsurface.
