Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
Roll bar assembly 1
Hex-head bolt (3/8 x 1-1/2 inch)
8
1
Nut (3/8 inch)
8
Install the roll bar .
2
Seat Kit (order separately; contact your
authorized T oro distributor)
1 Install the seat.
3
Service decal (Part Number 137-8052)
1 Install the service decal.
Steering wheel
1
Cap
1
W asher 1
4
Locknut 1
Install the steering wheel.
Grass-basket hook
6
5
Flange bolts 12
Install the grass-basket hooks.
Cutting unit (order separately; contact
your authorized T oro distributor)
3
Grass basket
3
Electric counterweight 3
Capscrew
6
6
O-ring
3
Install the cutting units.
7
No parts required
Connect the main-power connectors.
8
No parts required
Adjust the machine settings.
9
Rear W eight Kit (order separately;
contact your authorized T oro distributor)
1
Add rear weight (if applicable).
Production year decal 1
CE warning decal (Part Number
139-8321)
1
10
CE/UKCA decal (Part Number
138-9470)
1
Install the CE/UKCA decals (if required).
1 1
No parts required
Reduce the tire pressure.
12
No parts required
Mount the battery charger on a wall
(optional).
13
No parts required
Charge the batteries.
1 1
