g389174
Figure 10
1. Main-power connectors
2. Connector cover
8
Adjusting the Machine
Settings
No Parts Required
Procedure
Use the InfoCenter to adjust the machine settings;
refer to InfoCenter ( page 19 ) .
9
Adding Rear W eight
Parts needed for this procedure:
1
Rear W eight Kit (order separately; contact your
authorized T oro distributor)
Procedure
This machine complies with applicable standards with
the Rear W eight Kit installed. Refer to your authorized
T oro distributor for the Rear W eight Kit.
If the machine comes with a 3-Wheel Drive kit, you do
not need to install the Rear W eight Kit.
10
Installing the CE/UKCA
Decals
If Required (CE/UKCA-Compliant
Countries Only)
Parts needed for this procedure:
1 Production year decal
1
CE warning decal (Part Number 139-8321)
1
CE/UKCA decal (Part Number 138-9470)
Procedure
If you use this machine in a country that complies to
CE/UKCA standards, install the following decals and
hood latch:
• Production year decal and CE/UKCA decal :
apply the decals on the frame tube below the seat
and serial plate; refer to Figure 1 1 .
15
