ProductOverview
1
2
3
4
5
6
4
G020877
Figure37
1.Parkingbrakelever4.Motioncontrollever
2.Fuelcap(bothsides)5.Seat
3.Rollbar
6.Seatbelt
Figure38
1.Ignitionswitch
5.Oilpressurewarninglight
2.Enginecoolant
temperaturewarning
light
6.Chargeindicatorlight
3.Glowpluglight
7.Throttlelever
4.Powertakeoff(PTO)
Switch
8.Hourmeter
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure37andFigure38).
MotionControlLevers
Themotioncontrolleverscontroltheforwardandrearward
motionsaswellastheturningofthemachine.Referto
DrivingtheMachine(page33).
ParkingBrakeLever
Whenevertheengineisshutoff,engagetheparkingbraketo
preventaccidentalmovementofthemachine.Toengagethe
parkingbrake,pulltheparkingbrakeleverrearwardandup
(Figure39).Toreleasetheparkingbrake,pushtheparking
brakeleverforwardanddown.
G020866
Figure39
1.Parkingbrakelever
CAUTION
Donotparkthetractionunitonaslope.
IgnitionSwitch
Theignitionswitchhas3positions:Off,On/Preheat,and
Start.
ThrottleLever
Thethrottlelevercontrolsthespeedoftheengine.Moving
thethrottleleverforwardtowardtheFastpositionincreases
theenginespeed.MovingitrearwardtowardtheSlow
positiondecreasestheenginespeed.Thethrottlecontrolsthe
speedofthebladesand,inconjunctionwithmotioncontrol
levers,controlsgroundspeedofthemachine.Alwaysrunthe
machinewiththethrottleintheFastpositionwhencutting
grass.
PowerTakeOff(PTO)Switch
Thepowertake-off(PTO)switchstartsandstopsthemower
blades.
HourMeter
Thehourmeterrecordsthenumberofhourstheengine
hasoperated.ItoperateswhenthekeyswitchisintheRun
position.Usethesetimesforschedulingregularmaintenance.
