WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetaltractorcomponentscausing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsof
themachine.
8.Installthebatteryintothemachineandsecureit.
Note:Thebatteryshouldnotmoveorwigglewhen
pushed.
9.First,installthepositivecable(red)tothepositive(+)
terminalandthenthenegativecable(black)tothe
negative(-)terminalofthebattery.Slidetherubber
bootoverthepositiveterminaltopreventapossible
shortfromoccurring.
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcablescausingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
WARNING
Connectingcablestothewrongpostcould
damagetheelectricalsystemandresultin
personalinjury.
Note:Ensurethatthebatterycablesareroutedaway
fromanysharpedgesormovingparts.
5
InstallingtheMower
Deck/PolarTrac
Partsneededforthisprocedure:
1
MowerDeckorPolarTracKit(soldseparately)
InstallingaMowerDeckKit
1.Removethetractionunitfromtheshippingpallet.
2.Placeajackstandundereachwheelmotorandaoor
jackundertherearbumper(Figure7),orsuspendfrom
aover-headhoist.
Figure7
1.Rearbumper2.Floorjack
3.Installthedrivetires(Figure8).
Figure8
1.Drivetire
