BleedingAirfromtheInjectors
Note:Usethisprocedureonlyifthefuelsystemhasbeen
purgedofairthroughnormalprimingproceduresandengine
willnotstart;refertoBleedingtheFuelSystem(page49).
1.Placearagunderthepipeconnectioncomingfrom
theinjectionpumptotheNo.1injectornozzleas
illustratedin
Figure69.
Figure69
1.PipeconnectionfromtheinjectionpumptotheNo.1
injectornozzle
2.MovethethrottletotheFastposition.
3.TurntheignitionkeytheStartposition,andwatchthe
fuelowaroundtheconnector.
CAUTION
Theenginemaystartduringthisprocedure.
Movingfansandbeltsinarunningenginecan
severelyinjureyouorbystanders.
Keephands,ngers,looseclothing/jewelry,
andhairawayfromtheenginefanandbelt
duringthisprocedure.
4.Tightenthepipeconnectorsecurelywhenitattainsa
solidow .
5.TurnthekeytotheOffposition.
6.Repeatthisprocedurefortheremainingnozzles.
ElectricalSystem
Maintenance
Important:Wheneverworkingwiththeelectrical
system,alwaysdisconnectthebatterycables,negative
(-)cablerst,topreventpossiblewiringdamagefrom
short-outs.
ServicingtheBattery
ServiceInterval:Every50hours
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Keepthetopofthebatteryclean.Ifyoustorethemachinein
alocationwheretemperaturesareextremelyhigh,thebattery
willrundownmorerapidlythanifthemachineisstoredina
locationwherethetemperatureiscool.
Keepthetopofthebatterycleanbywashingitperiodically
withabrushdippedinammoniaorbicarbonateofsoda
solution.Flushthetopsurfacewithwateraftercleaningit.
Donotremovethellcapswhilecleaningthebattery.
Thebatterycablesmustbetightontheterminalstoprovide
goodelectricalcontact.
Ifcorrosionoccursattheterminals,disconnectthecables,
negative(-)cablerst,andscrapetheclampsandterminals
separately.Connectthecables,positive(+)cablerst,and
coattheterminalswithpetroleumjelly.
WARNING
Batteryterminalsormetaltoolscouldshortagainst
metalmachinecomponentscausingsparks.Sparks
cancausethebatterygassestoexplode,resulting
inpersonalinjury.
•Whenremovingorinstallingthebattery,donot
allowthebatteryterminalstotouchanymetal
partsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
