ChangingtheEngineOilAndFilter
ServiceInterval:Aftertherst50hours
Every150hours
Changetheoilandlterinitiallyafterrst50hoursof
operationandthenevery150hoursofoperationthereafter.If
possible,runtheenginejustbeforechangingtheoilbecause
warmoilowsbetterandcarriesmorecontaminantsthan
coldoil.
1.Positionthemachineonalevelsurface.
2.Openthehood.
3.Setadrainpanundertheoilpanandinlinewiththe
drainplug(
Figure66).
Figure66
1.Oillter
2.Drainplug
4.Cleantheareaaroundthedrainplug.
5.Removethedrainplugandallowtheoiltoowinto
drainpan.
6.Removeandreplacetheoillter(
Figure66).
7.Aftertheoilisdrained,installthedrainplugandwipe
upanyoilthatisspilled.
8.Fillthecrankcasewithoil;refertoCheckingtheEngine
OilLevel(page30).
FuelSystem
Maintenance
Note:RefertoAddingFuel(page29)forproperfuel
recommendations.
DANGER
Undercertainconditions,dieselfuelandfuel
vaporsarehighlyammableandexplosive.Are
orexplosionfromfuelcanburnyouandothersand
cancausepropertydamage.
•Useafunnelandllthefueltankoutdoors,in
anopenarea,whentheengineisoffandiscold.
Wipeupanyfuelthatspills.
•Donotllthefueltankcompletelyfull.Addfuel
tothefueltankuntilthelevelistothebottom
ofthellerneck.
•Neversmokewhenhandlingfuel,andstayaway
fromanopenameorwherefuelfumesmaybe
ignitedbyaspark.
•Storefuelinaclean,safety-approvedcontainer
andkeepthecapinplace.
ServicingtheWaterSeparator
ServiceInterval:Every400hours
Every400hours
Drainwaterorothercontaminantsfromwaterseparator
(
Figure67)daily.
1.Placeacleancontainerunderthefuellter.
2.Loosenthedrainplugonthebottomofthelter
canister.
Figure67
1.Waterseparatorltercanister
3.Cleantheareawheretheltercanistermounts.
4.Removetheltercanisterandcleanthemounting
surface.
5.Lubricatethegasketontheltercanisterwithcleanoil.
48
