Toro 30381 - Adjusting the Control Lever Neutral Return

Figure80
1.Controllever3.Screws
2.Neutralinterlockswitch
4.0.015to0.045inch(0.4to
1mm)
4.Holdingthecontrolleveragainsttheframe,movethe
switchtowardtheleveruntilthedistancebetweenlever
andswitchbodyis0.015to0.045inch(0.4to1mm)
(Figure80).
5.Securetheswitch.
6.Repeatsteps3to5fortheotherlever.
7.Installthefrontpanel.
AdjustingtheControlLever
NeutralReturn
Ifthemotioncontrolleversdonotalignwiththeneutralslots
whenreleasedfromthereversedriveposition,adjustmentis
required.Adjusteachlever,spring,androdseparately.
1.DisengagethePTO,movethecontrollevertothe
neutrallockedposition,andsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Removetheboltssecuringthefrontpanelandremove
thepanel(
Figure81).
1
2
G020875
Figure81
1.Bolts
2.Controlpanel
4.Movethecontrollevertotheneutralpositionbutnot
locked(Figure83).
5.Pulltheleverbackuntiltheclevispin(onanarm
abovethepivotshaft)contactstheendoftheslot(just
beginningtoputpressureonthespring)(
Figure82).
Figure82
1.Clevispin
4.Adjustmentbolt
2.Slot
5.Yoke
3.Jamnuts
57
