Toro 30383 - Product Overview; Controls

ProductOverview
Figure3
1.Track5.Doorlatch
2.Frontliftarm6.Fuelcap(bothsides)
3.Windshieldwiper7.Hood
4.Worklights
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure3andFigure4).
Figure4
TractorControlPanel
1.Ignitionswitch
5.Oilpressurewarninglight
2.Enginecoolant
temperaturewarning
light
6.Chargeindicatorlight
3.Glowpluglight
7.Throttlelever
4.Powertakeoff(PTO)
Switch
8.Hourmeter
MotionControlLevers
Themotioncontrolleverscontroltheforwardand
rearwardmotionsaswellastheturningofthemachine.
ParkingBrakeLever
Whenevertheengineisshutoff,engagetheparking
braketopreventaccidentalmovementofthemachine.
Toengagetheparkingbrake,pulltheparkingbrakelever
rearwardandup(Figure5).Toreleasetheparkingbrake,
pushtheparkingbrakeleverforwardanddown.
Figure5
1.Parkingbrakelever
Donotparkthemachineonaslope.
IgnitionSwitch
Theignitionswitchhasthreepositions:Off,
On/Preheat,andStart.
ThrottleLever
Thethrottlelevercontrolsthespeedoftheengine.
MovingthethrottleleverforwardtowardtheFast
positionincreasestheenginespeed.Movingitrearward
towardtheSlowpositiondecreasestheenginespeed.
Thethrottle,inconjunctionwithmotioncontrollevers,
controlsgroundspeedofthemachine.Alwaysrunthe
machinewiththethrottleintheFastpositionwhen
usingattachments.
PowerTakeOff(PTO)Switch
Thepowertakeoff(PTO)switchstartsandstops
poweredattachments.
HourMeter
Thehourmeterrecordsthenumberofhourstheengine
hasoperated.Itoperateswhenthekeyswitchisinthe
Runposition.Usethesetimesforschedulingregular
maintenance.
