Figure34
1.Oillter
2.Drainplug
4.Cleantheareaaroundthedrainplug.
5.Removethedrainplugandallowtheoiltoowinto
drainpan.
6.Removeandreplacetheoillter(Figure34).
7.Aftertheoilisdrained,installthedrainplugand
wipeupanyoilthatisspilled.
8.Fillthecrankcasewithoil;refertoCheckingthe
EngineOilLevel.
FuelSystem
Maintenance
Note:RefertoAddingFuelforproperfuel
recommendations.
Undercertainconditions,dieselfuelandfuel
vaporsarehighlyammableandexplosive.A
reorexplosionfromfuelcanburnyouand
othersandcancausepropertydamage.
•Useafunnelandllthefueltankoutdoors,
inanopenarea,whentheengineisoffand
iscold.Wipeupanyfuelthatspills.
•Donotllthefueltankcompletelyfull.Add
fueltothefueltankuntilthelevelistothe
bottomofthellerneck.
•Neversmokewhenhandlingfuel,andstay
awayfromanopenameorwherefuel
fumesmaybeignitedbyaspark.
•Storefuelinaclean,safety-approved
containerandkeepthecapinplace.
ServicingtheWaterSeparator
ServiceInterval:Beforeeachuseordaily—Drain
water/contaminantsfromthewater
separator.
Every400hours—Replacethefuel
ltercanister.
1.Placeacleancontainerunderthefuellter.
2.Loosenthedrainplugonthebottomofthelter
canister.
