Toro 30383 - Adjusting the Tracking

4.Loosenthejamnutonthestopboltforoneofthe
controllevers(Figure54).
Figure54
1.Stopbolt
3.Jamnut
2.Controllever4.0.060inch(1.5mm)
5.Threadthestopboltallthewayin(awayfromthe
controllever).
6.Pushthecontrolleverallthewayforwarduntilit
stopsandholditthere.
7.Threadthestopboltout(towardsthecontrollever)
untilthereisagapof0.060inch(1.5mm)between
theheadofthestopboltandthecontrollever.
8.Tightenthejamnuttosecurethestopboltinplace.
9.Repeatsteps4through8fortheothercontrollever.
10.Installthefrontpanel.
AdjustingtheTracking
1.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedpositionandsettheparking
brake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingparts
tostopbeforeleavingtheoperatingposition.
3.Loosentheboltssecuringthecontrollevers
(Figure55)
Figure55
1.Controllever
3.Bolts
2.Controlleverpost
4.Havesomeonepushthecontrolleverposts(notthe
controllevers)allthewayforwardintothemaximum
speedpositionandholdthemthere.
5.Adjustthecontrolleverssothattheylineup
(
Figure56)andtightenthebolts,securingthelevers
totheposts.
Figure56
