Toro 30383 - Adjusting the Traction Drive for Neutral

Figure50
1.Clevispin
4.Adjustmentbolt
2.Slot
5.Yoke
3.Jamnuts
6.Checkwherethecontrolleverisrelativetonotchin
console(Figure51).Itshouldbecenteredallowing
levertopivotoutwardtotheneutrallockposition.
Figure51
1.Neutralposition2.Neutrallockedposition
7.Ifadjustmentisneeded,loosenthenutandjamnut
againsttheyoke(Figure50).
8.Applyingslightrearwardpressureonthemotion
controllever,turntheheadoftheadjustmentbolt
intheappropriatedirectionuntilthecontrolleveris
centeredintheneutrallockposition(Figure50).
Note:Keepingrearwardpressureontheleverwill
keepthepinattheendoftheslotandallowthe
adjustmentbolttomovethelevertotheappropriate
position.
9.Tightenthenutandjamnut(Figure50).
10.Repeatsteps4through9fortheothercontrollever.
11.Installthefrontpanel.
AdjustingtheTractionDrive
forNeutral
Thisadjustmentmustbemadewithtracksturning.
Mechanicalorhydraulicjacksmayfailto
supportmachineandcauseaseriousinjury.
•Usejackstandswhensupportingmachine.
•Donotusehydraulicjacks.
Theenginemustberunningtoperformthis
adjustment.Contactwithmovingpartsorhot
surfacesmaycausepersonalinjury.
Keephands,feet,face,clothing,andotherbody
partsawayfromrotatingparts,mufer,and
otherhotsurfaces.
1.Raisetheframeontostablejackstandssothatthe
trackscanrotatefreely.
2.Slideseatforward,unlatchit,andswingitupand
forward.
3.Disconnecttheelectricalconnectorfromtheseat
safetyswitch.Temporarilyinstallajumperwire
acrossterminalsinthewiringharnessconnector.
4.Starttheengine,ensurethatthethrottleleveris
midwaybetweentheFastandSlowpositions,and
releasetheparkingbrake
Note:Themotioncontrolleversmustbein
theneutrallockedpositionwhilemakingany
adjustments.
5.Adjustthepumprodlengthononesidebyrotating
thehexshaft,intheappropriatedirection,untilthe
correspondingwheelisstillorslightlycreepingin
reverse(Figure52).
40
