Toro 30383 - Cleaning the Fuel Tank; Replacing the Fuel Pre-Filter; Fuel Lines and Connections; Bleeding the Fuel System

Figure35
1.Waterseparator2.Drainplug
3.Cleantheareawheretheltercanistermounts.
4.Removetheltercanisterandcleanthemounting
surface.
5.Lubricatethegasketontheltercanisterwithclean
oil.
6.Installtheltercanisterbyhanduntilthegasket
contactsmountingsurface,thenrotateitan
additional1/2turn.
7.Tightenthedrainplugonthebottomofthelter
canister.
CleaningtheFuelTank
ServiceInterval:Every2years
Note:Also,drainandcleanthetankifthefuelsystem
becomescontaminatedorifthemachineistobestored
foranextendedperiod.
Usecleandieselfueltoushoutthetank.
ReplacingtheFuelPre-Filter
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
Thefuelpre-lter(Figure36)islocatedbetweenthefuel
tankandfuelpump.
1.Clampbothfuellinesthatconnecttothepre-lter
sofuelcannotdrainwhenthelinesareremoved
(Figure36).
Figure36
1.Hoseclamps
2.Fuelprelter
2.Loosenthehoseclampsatbothendsofthelter
andpullthefuellinesoffofthelter.
3.Slidethehoseclampsontoendsofthefuellines.
4.Pushfuellinesontothepre-lterandsecurethem
withhoseclamps.
Important:Ensurethatthearrowonthesideof
thelterpointstowardtheinjectionpump.
FuelLinesandConnections
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
Inspectthefuellinesfordeterioration,damage,chafng,
orlooseconnections.
BleedingtheFuelSystem
1.Parkthemachineonalevelsurface.Ensurethatthe
fueltankisatleasthalffull.
2.Unlatchandraisethehood.
3.Placearagundertheairbleedscrewonthefuel
injectionpumpandopenit(Figure37).
