Figure21
1.Sidepanelcover
2.Latches
OnthefaceoftheSCMare11LEDsthatilluminate
toindicatevarioussystemconditions.Sevenofthese
lightscanbeusedbytheoperatorforsystemdiagnosis.
RefertoFigure22foradescriptionofwhateach
lightmeans.FordetailsonusingtherestoftheSCM
functions,refertotheServiceManual,availablethrough
yourAuthorizedToroDistributor.
Figure22
1.Hightemperatureshutdown—theenginetemperaturehas
exceededsafelevelsandtheenginehasbeenshutdown.
Checkthecoolingsystem.
2.Hightemperaturewarning—theenginetemperatureis
approachingunsafelevelsandthePTOhasbeenshut
down.Checkthecoolingsystem.
3.Operatorisintheseat
4.ThePTOisOn
5.Theparkingbrakeisnotengaged
6.ControlsareinNeutral
7.TheSCMisreceivingpowerandisoperational
PositioningtheSeat
ChangingtheSeatPosition
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
1.Toadjust,movetheleversidewaystounlockthe
seat(Figure23).
G006855
1234
Figure23
1.Backrestknob3.Lumbarsupport
adjustmentknob
2.Seatsuspensionknob4.Seatpositionadjustment
lever
2.Slidetheseattothedesiredpositionandrelease
levertolockinposition.
3.Verifythattheseathaslockedintoplaceby
attemptingtomoveitbackandforth.
ChangingtheSeatSuspension
Theseatcanbeadjustedtoprovideasmoothand
comfortableride.Positiontheseatwhereyouaremost
comfortable.
Withoutsittingontheseat,turntheknobinfronteither
directiontoprovidethebestcomfort(Figure23).
