WARNING
Hydraulicuidescapingunderpressurecan
penetrateskinandcauseinjury.
•Ifhydraulicuidisinjectedintotheskin
itmustbesurgicallyremovedwithinafew
hoursbyadoctorfamiliarwiththistypeof
injury.Gangrenemayresultifthisisnot
done.
•Keepbodyandhandsawayfrompinhole
leaksornozzlesthatejecthighpressure
hydraulicuid.
•Usecardboardorpapertondhydraulic
leaks.
•Safelyrelieveallpressureinthehydraulic
systembeforeperforminganyworkonthe
hydraulicsystem.
•Makesureallhydraulicuidhosesand
linesareingoodconditionandallhydraulic
connectionsandttingsaretightbefore
applyingpressuretohydraulicsystem.
ReplacingtheHydraulicFilterand
HydraulicOil
ServiceInterval:Aftertherst8hours
Every250hours—Changethe
hydrauliclterandhydraulicoilwhen
usingMobil
®
1oil.
Every500hours—Changethe
hydrauliclterandhydraulicoil
whenusingToro
®
HYPR-OIL
™
500
hydraulicoil.
WARNING
Hothydraulicuidcancausesevereburns.
Allowthehydraulicuidtocoolbeforeperforming
anymaintenancetothehydraulicsystem.
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
Important:Donotsubstituteautomotiveoil
lterorseverehydraulicsystemdamagemay
result.
3.Locatethelterunderthefueltankandplacedrain
panunderlter(Figure60).
Figure60
4.Removetheoldlter,allowtheoiltodrainandwipe
thelteradaptergasketsurfaceclean(Figure61).
5.Applyathincoathydraulicuidtotherubbergasket
onthereplacementlter.
6.Installreplacementhydrauliclterontothelter
adapter.Donottighten.
7.Fillthehydraulictankwithhydraulicuiduntilthe
uidoverowsthelterandthenturntheoillter
clockwiseuntiltherubbergasketcontactsthelter
adapter,thentightenthelteranadditional1/2turn
(
Figure61).
Figure61
1.Hydrauliclter
3.Adapter
2.Gasket
8.Cleanupanyspilleduid.
9.Checktheuidinthereservoir,adduidtothetank
untilitreachesthecoldbafeofthetank.
Important:Useoilspecied.Otheruids
couldcausesystemdamage.
10.Startengineandletrunforabouttwominutesto
purgeairfromthesystem.Stoptheengineand
43
