G004501
123456
7
Figure31
1.Aircleanercover5.Aircleanerbody
2.Aircleanerlatch6.Aircleanerindicator
3.Gasket
7.Rubberoutletvalve
4.Filter
3.Besurethecoverisseatedcorrectlyandsealswiththe
aircleanerbody.
ServicingtheAirCleaner
ServiceInterval:Every400hours
1.Pullthelatchoutwardandrotatetheair-cleanercover
counter-clockwise(Figure31).
2.Removethecoverfromtheair-cleanerbody(Figure
31).
3.Beforeremovingthelter,uselowpressureair(40psi,
cleananddry)tohelpremovelargeaccumulationsof
debrispackedbetweenoutsideofprimarylterand
thecanister.
Thiscleaningprocesspreventsdebrisfrommigrating
intotheintakewhentheprimarylterisremoved.
Important:Avoidusinghigh-pressureairwhich
couldforcedirtthroughthelterintotheintake
tract.
4.Removeandreplacetheprimarylter(Figure31).
Important:Donotcleantheusedelementto
avoiddamagetotheltermedia.
5.Inspectthenewlterforshippingdamage,checking
thesealingendofthelterandthebody.
Important:Donotuseadamagedelement.
6.Ensurethatthefoamgasketisinplaceinthecoverand
thatitisnottornordamaged(Figure31).
Note:Ifitisdamaged,replaceit.
7.Insertthenewlterbyapplyingpressuretotheouter
rimoftheelementtoseatitinthecanister.
Important:Donotapplypressuretotheexible
centerofthelter.
8.Cleanthedirtejectionport(locatedintheremovable
cover)asfollows:
A.Removetherubberoutletvalvefromthecover
(Figure31).
B.Cleanthecavity.
C.Replacetheoutletvalve.
9.Installthecoverorientingtherubberoutletvalveina
downwardposition—betweenapproximately5:00to
7:00whenviewedfromtheend.
10.Resettheindicator(Figure31)ifshowingred.
ServicingtheEngineOil
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Theengineisshippedwithoilinthecrankcase;however,the
oillevelmustbecheckedbeforeandaftertheengineisrst
started.
Thecrankcasecapacityis5.2liters(5.5qt)withthelter.
Usehigh-qualityengineoilthatmeetsthefollowing
specications:
•APIClassicationLevelRequired:CJ-4orhigher.
•Preferredoil:SAE15W-40(above0°F)
•Alternateoil:SAE10W-30or5W-30(alltemperatures)
Important:UsingnonCJ-4orhigheroilwillcause
DPFplugginganddamagetheengine.
ToroPremiumEngineOilisavailablefromyourdistributor
ineither15W-40or10W-30viscosity.Seethepartscatalog
forpartnumbers.
Note:Thebesttimetochecktheengineoiliswhenthe
engineiscoolbeforeithasbeenstartedfortheday.Ifithas
alreadybeenrun,allowtheoiltodrainbackdowntothe
sumpforatleast10minutesbeforechecking.Iftheoillevel
isatorbelowthe“add”markonthedipstick,addoiltobring
theoilleveltothe“full”mark.DONOTOVERFILL.
Iftheoillevelisbetweenthe“full”and“add”marks,no
additionaloilisrequired.
1.Parkthemachineonalevelsurface.Unlocktheengine
coverlatches.
2.Opentheenginecover.
3.Removethedipstick,wipeitclean,installthedipstick
intothetube,andpullitoutagain.Theoillevelshould
bebetweenthefullandaddmarks(Figure32).
