Toro 30695 - Changing the Hydraulic Oil and Filter; Cleaning; Waste Disposal

ChangingtheHydraulicOil
AndFilter
ServiceInterval:Aftertherst200hours
Every800hours
1.DisengagethePTO,movethemotioncontrolleversto
theneutrallockedposition,andsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Placealargepanunderthehydraulicreservoirand
transmissioncaseandremovetheplugs,drainingallof
thehydraulicuid(Figure55).
Figure55
1.Hydraulicreservoirdrain
plug
3.Transmissioncasedrain
plug
2.Filter
4.Cleantheareaaroundthehydraulicoillterand
removeit(Figure55).
5.Immediatelyinstallanewhydraulicoillter.
6.Installthehydraulicreservoirandtransmissioncase
drainplugs.
7.Fillthereservoirtotheproperlevel(approximately6
quarts);refertoCheckingtheHydraulicSystem.
8.Starttheengineandcheckforoilleaks.Allowthe
enginetorunforaboutveminutes,thenshutitoff.
9.After2minutes,checkthelevelofthehydraulicuid;
refertoCheckingtheHydraulicSystem.
Cleaning
WasteDisposal
Engineoil,batteries,hydraulicoil,andenginecoolantare
pollutants.Disposeoftheseaccordingtoyourstateandlocal
regulations.
