Toro 30695 - Adjusting the Maximum Ground Speed; Adjusting the Tracking

9.Repeatsteps6through8fortheothersideofthe
machine.
10.Tightenthejamnutsattheballjoints(Figure47).
11.MovethethrottlelevertotheSlowpositionandstop
theengine.
12.Removethejumperwirefromthewireharness
connectorandplugtheconnectorintotheseatswitch.
WARNING
Electricalsystemwillnotperformproper
safetyshutoffwithjumperwireinstalled.
•Removejumperwirefromwireharness
connectorandplugconnectorintoseat
switchwhenadjustmentiscompleted.
•Neveroperatethisunitwithjumper
installedandseatswitchbypassed.
13.Lowertheseatintoposition.
14.Removethejackstands.
AdjustingtheMaximum
GroundSpeed
1.DisengagethePTO,movethemotioncontrolleversto
theneutrallockedposition,andsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Removetheboltssecuringthefrontpanelandremove
thepanel(Figure50).
1
2
G020875
Figure50
1.Bolts
2.Controlpanel
4.Loosenthejamnutonthestopboltforoneofthe
controllevers(Figure51).
Figure51
1.Stopbolt
3.Jamnut
2.Controllever4.1.5mm(0.060inch)
5.Threadthestopboltallthewayin(awayfromthe
controllever).
6.Pushthecontrolleverallthewayforwarduntilitstops
andholditthere.
7.Threadthestopboltout(towardthecontrollever)
untilthereisagapof1.5mm(0.060inch)betweenthe
headofthestopboltandthecontrollever.
8.Tightenthejamnuttosecurethestopboltinplace.
9.Repeatsteps4through8fortheothercontrollever.
10.Installthefrontpanel.
Note:Ifyouwishtoreducethemaximummachinespeed,
setthespeedforbothcontrolleversasdirectedabove,then
backeachstopboltoutanequalamounttowardthecontrol
leveruntilyoureachthemaximumspeedyoudesire(youwill
likelyhavetotestyouradjustmentseveraltimes).Ensurethat
themachinedrivesstraightanddoesnotturnwhenboth
controlleversarepushedallthewayforward.Ifthemachine
turns,youdonothavethestopboltsevenlysetandwillneed
toadjustthemfurther.
AdjustingtheTracking
1.DisengagethePTO,movethemotioncontrolleversto
theneutrallockedpositionandsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Loosentheboltssecuringthecontrollevers(Figure52)
45
