FuelSystem
Maintenance
Note:RefertoAddingFuel(page16)forproperfuel
recommendations.
DANGER
Undercertainconditions,dieselfuelandfuel
vaporsarehighlyammableandexplosive.Are
orexplosionfromfuelcanburnyouandothersand
cancausepropertydamage.
•Useafunnelandllthefueltankoutdoors,in
anopenarea,whentheengineisoffandiscold.
Wipeupanyfuelthatspills.
•Donotllthefueltankcompletelyfull.Addfuel
tothefueltankuntilthelevelistothebottom
ofthellerneck.
•Neversmokewhenhandlingfuel,andstayaway
fromanopenameorwherefuelfumesmaybe
ignitedbyaspark.
•Storefuelinaclean,safety-approvedcontainer
andkeepthecapinplace.
ServicingtheWaterSeparator
ServiceInterval:Every400hours
Every400hours
Drainwaterorothercontaminantsfromwaterseparator
(Figure34)daily.
1.Placeacleancontainerunderthefuellter.
2.Loosenthedrainplugonthebottomofthelter
canisterandopentheventonthetopofthecanister
mount.
Figure34
1.Waterseparatorltercanister
3.Cleantheareawheretheltercanistermounts.
4.Removetheltercanisterandcleanthemounting
surface.
5.Lubricatethegasketontheltercanisterwithcleanoil.
6.Installtheltercanisterbyhanduntilthegasket
contactsmountingsurface,thenrotateitanadditional
1/2turn.
7.Tightenthedrainplugonthebottomofthelter
canisterandclosetheventonthetopofthecanister
mount.
ServicingtheEngineFuel
Filter
ServiceInterval:Every400hours
Theenginefuelltershouldbereplacedafterevery400
hoursofoperation.
1.Cleantheareaaroundthefuellterhead(Figure35).
g021576
1
2
Figure35
1.FuelFilterhead2.FuelFilter
2.Removethelterandcleanthelterheadmounting
surface(Figure35).
3.Lubricatetheltergasketwithcleanlubricatingengine
oil.RefertotheEngineOperator'sManual,included
withthemachine,foradditionalinformation.
4.Installthedryltercanister,byhand,untilthegasket
contactsthelterhead,thenrotateitanadditional
1/2turn.
5.Starttheengineandcheckforfuelleaksaroundthe
lterhead.
CleaningtheFuelTank
ServiceInterval:Every2years
Drainandcleanfueltankevery2years.Also,removeand
cleanthein-linestrainersafterdrainingthetank.Useclean
dieselfueltoushoutthetank.
Important:Drainandcleanthetankifthefuelsystem
becomescontaminatedorifthemachineistobestored
foranextendedperiod.
