InfoCenterIconDescription(cont'd.)
Starttheengine.
ThePTOison.
Thecruisecontrolison.
Shutofftheengine
Engine
Keyswitch
Cuttingunitsarelowering
Cuttingunitsareraising
PINcode
Hydraulicuidtemperature
CANbus
InfoCenter
Badorfailed
Center
Right
Left
Bulb
OutputofTECcontrollerorcontrol
wireinharness
Overtheallowedrange
Undertheallowedrange
/
Outofrange
Switch
Operatormustreleaseswitch
InfoCenterIconDescription(cont'd.)
Operatorshouldchangetoindicated
state
Symbolsareoften
combinedtoform
sentences.Some
examplesareshown
below
Operatorshouldputmachinein
neutral
Enginestartisdenied
Engineshutdown
Enginecoolantistoohot
Hydraulicuidistoohot
DPFashaccumulationnotication.
RefertoServicingtheDiesel
ParticulateFilter(DPF)inthe
maintenancesectionfordetails
Reset-standbyregenerationrequest
Parkedorrecoveryregeneration
request
Aparkedorrecoveryregenerationis
processing.
Highexhausttemperature
Thepowertake-offisdisabled.
Sitdownorengageparkingbrake
AccessibleonlybyenteringPIN
