Toro 30881 - Locating the Fuses

WARNING
Incorrectbatterycableroutingcould
damagethemachineandcables,causing
sparks.Sparkscancausethebattery
gassestoexplode,resultinginpersonal
injury.
•Alwaysdisconnectthenegative
(black)batterycablebefore
disconnectingthepositive(red)
cable.
•Alwaysconnectthepositive(red)
batterycablebeforeconnectingthe
negative(black)cable.
WARNING
Batteryterminalsormetaltoolscould
shortagainstmetalcomponents,causing
sparks.Sparkscancausethebattery
gassestoexplode,resultinginpersonal
injury.
•Whenremovingorinstallingthe
battery,donotallowthebattery
terminalstotouchanymetalpartsof
themachine.
•Donotallowmetaltoolstoshort
betweenthebatteryterminalsand
metalpartsofthemachine.
g009986
Figure93
1.Positivebatterycable2.Negativebatterycable
4.Connecta3to4Abatterychargertothebattery
posts.Chargethebatteryatarateof3to4Afor
4to8hours.
WARNING
Chargingthebatteryproducesgasses
thatcanexplode.
Neversmokenearthebatteryandkeep
sparksandamesawayfrombattery.
5.Whenthebatteryischarged,disconnectthe
chargerfromthepoweroutletandbatteryposts.
6.Installthepositivecable(red)tothepositive(+)
terminalandthenegativecable(black)tothe
negative(-)terminalofthebattery(Figure93).
7.Securethecablestothepostswithboltsand
nuts.
Note:Makesurethatthepositive(+)terminal
isallthewayonthepostandthecableis
positionedsnugtothebattery.Thecablemust
notcontactthebatterycover.
8.CoatbothbatteryconnectionswithGrafo112X
(skin-over)grease,PartNo.505-47,petroleum
jelly,orlightgreasetopreventcorrosion.
9.Slidetherubberbootoverthepositiveterminal.
10.Closetheconsolepanelandsecurethelatch.
LocatingtheFuses
Thefuseblockforthemachineislocatedintheright
storagebox
decal125-4605
Figure94
1.Loosenthelatchforthecoveroftheright
storageboxandraisethecover(Figure95)to
exposethefuseblock(Figure96).
