Toro 30881 - Drive System Maintenance; Checking for End-Play in the Planetary Drives

g009985
Figure95
1.Latch2.Rightstoragebox
2.Replacetheopenfuse(s)asneeded(Figure96).
g010255
Figure96
1.Fuses
3.Closethecoveroftherightstorageboxand
securethecoverwiththelatch(Figure95).
DriveSystem
Maintenance
g225611
Figure97
CheckingforEnd-Playin
thePlanetaryDrives
ServiceInterval:Every400hours
Thereshouldbenoend-playintheplanetary
drives/drivewheels(i.e.,thewheelsshouldnotmove
whenyoupullorpushtheminadirectionparallelto
theaxle).
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,lowerthecuttingunits,shutoff
theengine,andremovethekey.
2.Chocktherearwheelsandraisethefrontof
machine,supportingthefrontaxle/frameonjack
stands.
DANGER
Amachineonajackmaybeunstableand
slipoffthejack,injuringanyonebeneath
it.
•Donotstarttheenginewhilethe
machineisonajack.
•Alwaysremovethekeyfromthe
switchbeforegettingoffthemachine.
•Blockthetireswhenyouareraising
themachinewithajack.
•Supportthemachinewithjackstands.
3.Grasp1ofthefrontdrivewheelsandpush/pullit
towardandawayfromthemachine,notingany
movement.
65
