Toro 30881 - Adjusting the Roller Scraper (Optional); Installing the Mulching Baffle (Optional)

3
AdjustingtheRoller
Scraper(Optional)
NoPartsRequired
Procedure
Theoptionalrearrollerscraperisdesignedtowork
bestwhenthereisanevengapof0.5to1mm(0.020
to0.040inch)betweenthescraperandroller.
1.Loosenthegreasettingandthemounting
screw(Figure7).
g011346
Figure7
1.Rollerscraper
3.Greasetting
2.Mountingscrew
2.Slidethescraperupordownuntilyouattain
agapof0.5to1mm(0.020to0.040inch)
betweentherodandtheroller.
3.Securethegreasettingandscrewto41N∙m
(30ft-lb)inanalternatingsequence.
4
InstallingtheMulching
Bafe(Optional)
NoPartsRequired
Procedure
1.Thoroughlycleandebrisfromthemountingholes
ontherearwallandleftwallofthechamber.
2.Installthemulchingbafeintherearopening
andsecureitwith5ange-headbolts(Figure8).
g011347
Figure8
1.Mulchingbafe
3.Verifythatmulchingbafedoesnotinterferewith
thetipofthebladeanddoesnotprotrudeinside
thesurfaceoftherearchamberwall.
DANGER
Usingthehigh-liftbladewiththe
mulchingbafecouldcausetheblade
tobreak,resultinginpersonalinjuryor
death.
Donotusethehigh-liftbladewiththe
mulchingbafe.
