2.Removethe2rivetssecuringthehood-latch
brackettothehood(Figure3).Removethe
hood-latchbracketfromthehood.
g012628
Figure3
1.Hood-latchbracket2.Rivets
3.Whilealigningthemountingholes,positionthe
CElockbracketandthehood-latchbracketonto
thehood(Figure4).
Note:Thelockbracketmustbeagainstthe
hood.Donotremovetheboltandnutfromthe
lock-bracketarm.
g012629
Figure4
1.CElockbracket
2.Boltandnut
4.Alignthewasherswiththeholesontheinsideof
thehood.
5.Rivetthebracketsandthewasherstothehood
(Figure4).
6.Hookthelatchontothehood-latchbracket
(Figure5).
g012630
Figure5
1.Hoodlatch
7.Screwtheboltintotheotherarmofthe
hood-latchbrackettolockthelatchinposition
(Figure6).Tightentheboltbutdonottighten
thenut.
g012631
Figure6
1.Bolt
3.Armofhood-latchbracket
2.Nut
