A.Rightnozzle—recordtheconverted
collected-waterquantityhere:
.
B.Centernozzle—recordtheconverted
collected-waterquantityhere:
.
C.Leftnozzle—recordtheconverted
collected-waterquantityhere:
.
2.Calculatetheowrateofeachnozzleusingthe
calculatedow-rateformula.
3.
CalculatedFlow-RateFormula
Formula
Result(X)L(USgallon)
x60seconds
19.7seconds
=
(X)L(US
gallon)
.49L(0.13USgallon)
x60seconds
Examplecenter
nozzle—narrow
pattern(red)
19.7seconds
=
3.07L
(0.40US
gallon)per
minute
A.Rightnozzle—recordthecalculatedow
ratehere:
.
B.Centernozzle—recordthecalculated
owratehere:
.
C.Leftnozzle—recordthecalculatedow
ratehere:
.
Note:Ifthecollectednozzlespraydoesnot
meetthequantityintheNozzleApplicationRate
Tables(page42),checkthenozzles,hoses,
andttingsforleaks,damage,orwear;cleanor
replacethespraynozzlesifneeded.
NozzleApplicationRateTables
Usethenozzletablesdeterminesprayerperformance:
•Nozzleowratesatdifferentspray-system
pressures
•Wornordamagedspraynozzles
Thetablesthatfollowincludeapplicationrate
informationforTeeJetTurboFloodJet®wideangle
fatspraytips:
Thetableexcerptisprovidedwithpermission
fromTeeJet
®
Technologies;referencetheTeeJet
®
Technologieswebsiteformoreinformation.
Important:Donotusethegreenandblack
nozzles(notlisted)withthismachinebecausethe
nozzlesexceedthespraypumpcapacity.
Thenozzleapplicationrateinformationisbasedon
watersprayedat21
°
C(70
°
F).
RedNozzleTable
Spray
Pressure
SingleNozzleRate
0.7Bar
(10psi)
0.77L/min
0.20gpm
26oz/min
1.4Bar
(20psi)
1.06L/min
0.28gpm
36oz/min
2.1Bar
(30psi)
1.33L/min
0.35gpm
45oz/min
2.8Bar
(40psi)
1.51L/min
0.40gpm
51oz/min
BrownNozzleTable
Spray
Pressure
SingleNozzleRate
0.7Bar
(10psi)
0.95L/min
0.25
gpmgpm
32oz/min
1.4Bar
(20psi)
1.33L/min
0.35gpm
45oz/min
2.1Bar
(30psi)
1.63L/min
0.43gpm
55oz/min
2.8Bar
(40psi)
1.89L/min
0.50gpm
64oz/min
