3.Cleanthegreasettingswitharag.Makesureto
scrapeanypaintoffthefrontofthetting(s).
4.Connectagreaseguntothetting.Pumpgrease
intothettingsuntilgreasebeginstooozeoutof
thebearings.
5.Wipeupanyexcessgrease.
LubricatingtheCasterand
WheelBearings
1.Lubricatethefrontwheelbearingsandfrontspindles
(Figure15).
2.Lubricatethedrivewheelbearings.
Figure15
GreasingtheTransmission
Couplers
Lubricatethetransmissioncouplerslocatedintheback
ofthemachine(Figure16).
Figure16
GreasingtheMowerBeltIdler
Greasethettingonthemowerbeltidlerarmpivot
(Figure17).
Note:Removethemowerdeckcovertoaccessthe
greasettingforthemowerbeltidlerarm.
Figure17
