Toro 38682 - Product Overview; Controls

106-2737
1.Park3.Neutral5.Engine—run
2.Drive4.Engine—stop6.Warning—wearearprotection.
ProductOverview
Figure3
1.Sidedischarge5.Controls
2.Mowerdeck6.Handle
3.Recoilstarter
7.Casterwheel
4.Gastank
Controls
Becomefamiliarwithallthecontrols(Figure4)before
youstarttheengineandoperatethemachine.
Figure4
1.Throttlecontrol6.Drivelever
2.Ignitionswitch
7.Gearshiftlever
3.Neutral/parkingbrakelock8.Choke
4.OperatorPresence
Control(OPC)lever
9.Powertakeofflever(PTO)
5.Handle
ThrottleControl
Thethrottlecontrolhastwopositions:FastandSlow.
OperatorPresenceControl(OPC)
Levers
WhenyousqueezetheOPCleversagainstthehandles,
theOPCsystemsensesthattheoperatorisinthenormal
operatingposition.WhenyoureleasetheOPClevers,
theOPCsystemsensesthattheoperatorhasleftthe
normaloperatingposition,andthesystemwillstopthe
engineifeitherthegearshiftleverisnotintheneutral
positionorthebladecontrol(PTO)leverisengaged.
9
