Toro 38682 - Height of Cut Chart

HeightofCutChart
Numberofspacers
belowcaster
Numberof1/4inchbladespacersbelowspindle
AxlePosition
1/2inch
(13mm)
3/16inch(5
mm)
43210
A00
1inch(26
mm)
1–1/4inch
(32mm)
1–1/2inch
(38mm)
1–3/4inch
(45mm)
2inch(51
mm)
A01
1–1/8inch
(29mm)
1–3/8inch
(35mm)
1–5/8inch
(41mm)
1–7/8inch
(48mm)
2–1/8inch
(54mm)
A10
1–3/8inch
(35mm)
1–5/8inch
(41mm)
1–7/8inch
(48mm)
2–1/8inch
(54mm)
2–3/8inch
(60mm)
B01
1–3/8inch
(35mm)
1–5/8inch
(41mm)
1–7/8inch
(48mm)
2–1/8inch
(54mm)
2–3/8inch
(60mm)
B10
1–5/8inch
(41mm)
1–7/8inch
(48mm)
2–1/8inch
(54mm)
2–3/8inch
(60mm)
2–5/8inch
(67mm)
B11
1–3/4inch
(45mm)
2inch(51
mm)
2–1/4inch
(57mm)
2–1/2inch
(64mm)
2–3/4inch
(70mm)
B20
2inch(51
mm)
2–1/4inch
(57mm)
2–1/2inch
(64mm)
2–3/4inch
(70mm)
3inch(76
mm)
C
11
1–7/8inch
(48mm)
2–1/8inch
(54mm)
2–3/8inch
(60mm)
2–5/8inch
(67mm)
2–7/8inch
(73mm)
C
20
2–1/8inch
(55mm)
2–3/8inch
(60mm)
2–5/8inch
(67mm)
2–7/8inch
(73mm)
3–1/8inch
(79mm)
C
21
2–1/4inch
(57mm)
2–1/2inch
(64mm)
2–3/4inch
(70mm)
3inch(76
mm)
3–1/4inch
(83mm)
C
30
2–1/2inch
(64mm)
2–3/4inch
(70mm)
3inch(76
mm)
3–1/4inch
(83mm)
3–1/2inch
(89mm)
D21
2–3/8inch
(61mm)
2–5/8inch
(67mm)
2–7/8inch
(73mm)
3–1/8inch
(79mm)
3–3/8inch
(86mm)
D30
2–1/2inch
(64mm)
2–3/4inch
(70mm)
3inch(76
mm)
3–1/4inch
(82mm)
3–1/2inch
(89mm)
D31
2–3/4inch
(70mm)
3inch(76
mm)
3–1/4inch
(82mm)
3–1/2inch
(89mm)
3–3/4inch
(95mm)
D40
3inch(76
mm)
3–1/4inch
(82mm)
3–1/2inch
(89mm)
3–3/4inch
(95mm)
4inch(102
mm)
E31
2–7/8inch
(73mm)
3–1/8inch
(79mm)
3–3/8inch
(86mm)
3–5/8inch
(92mm)
3–7/8inch
(98mm)
E40
3–1/8inch
(79mm)
3–3/8inch
(86mm)
3–5/8inch
(92mm)
3–7/8inch
(98mm)
4–1/8inch
(105mm)
E41
3–1/4inch
(82mm)
3–1/2inch
(89mm)
3–3/4inch
(95mm)
4inch(102
mm)
4–1/4inch
(108mm)
