MOWER DECKS
6-24 Toro Z Master G3 3000/5000/6000 Series Service Manual
6
A. Adjustment nut C. Rear deck adjustment
B. Jam nut D. Front deck adjustment
A. Whizlock nut C. Jam nut
B. Adjuster screw D. Yoke
11. For mower decks shown below, ne-tune the
adjustment nut on the front deck lift-assembly by
turning it (Fig. 457).
Note: To increase the height, turn the adjustment
nut clockwise; to decrease, turn counter-
clockwise.
Fig. 456 g. 94 G012430
Fig. 457 g. 95 G010251
10. For mower decks shown below, ne-tune the
adjustment nut on the front deck lift-assembly by
turning it (Fig. 456).
Note: To increase the height, turn the adjustment
nut clockwise; to decrease, turn counter-
clockwise.
A
B
C
D
B
A
A B C D
