3.Alignthefourholesoftheenginebasetotheframeandattachthetworear
mountingboltsandtwoatwashersloosely.
Note:ApplyLoctite243toenginemountingbolts.
4.Attachthefrontboltthroughtheclutchanchorandintotheenginebase.
5.Installthe3remainingenginebolts.
6.Torquethe4enginemountingboltsto52±5.8N•m(450±50in-lb).
7.Applyanti-seizetotheclutchendofthecrankshaft.
8.Installtheenginepulleyontothecrankshaft.
9.Installtheclutchontothecrankshaftensuringthattheslotintheclutchaligns
withthetabontheclutchanchor.
10.Installthewasherandclutchbolt.
Note:ApplyLoctitetotheclutchbolt.
11.T orquetheclutchboltto69-83N•m(50-60ft-lb).
12.Connectthechokecable.
13.Connectthethrottlecable.
14.Connecttheblackenginegroundwire.
Note:ApplyLoctitetogroundbolt.
15.Connecttheredwiretothestarter.
g321704
Figure16
16.Connectthechassiswireharnesstothemainenginewireharness.
17.Connectthefuelsupplylinetothefuelpump.
18.Connecttheventlinetobarb/splice.
19.Installthehydrostaticdrivebelt.
20.Installthemowerbelt.
21.Installthemuferandnewexhaust.
Note:Torquemufermountingboltsornutsto17-20N•m(150-170in-lb).
