Toro 75746 - Fuel Tank Replacement

SeatandMyRIDE™Platform(MRModelsOnly)Installation(continued)
g321445
Figure38
6.Connectthefueltankventlineattothesplicetting.
7.Connectthefuelsupplylinetothefuellter.
8.Connecttheventlinekeeperstotheventlines.
9.Connectthewireharnessterminaltotheoperatorpresenceswitch.
10.Installtherelayandfuseholder.
11.Installtherightandleftsideconsoles.LeftConsoleReplacement(page5–6)
RightConsoleReplacement(page5–8)
12.Connectthebatterybyinstallingthepositivecablerst,thenthenegative
cabletothebattery.
13.Verifyproperfunction.
FuelTankReplacement
FuelTankRemoval
g321450
Figure39
1.FuelTankHold-DownRod3.VentLine
2.FuelSupplyLine
Chassis:ServiceandRepairs
Page5–18
TitanServiceManual
3438-774RevA
