RightConsoleRemoval(continued)
g321208
Figure23
4.Removethescrewssecuringthecontrolpanelassemblytotheconsole.
g321207
Figure24
5.Removetherightsidecontrollever.
6.Lifttheconsoleupwardoffofthemachine,whilefeedingthecontrolpanel
assemblythroughtheopeningintheconsole.
Note:Thecontrolpanelassemblyshouldbesupportedwhileservicingthe
machine,toavoiddamagetothecablesorwireharness.
TitanServiceManual
Page5–9
Chassis:ServiceandRepairs
3438-774RevA
