SeatRemoval(ZXModelsOnly)
1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stoptheengine,
waitforallmovingpartstostop,andremovekey.Engagetheparkingbrake.
2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
3.Disconnectthewireharnessconnectorattheoperatorpresenceswitch.
4.Removethecotterpinsfromthestoprodontheleftandrightsidesofthe
seat.
5.Slidetherodtowardtheinsideoftheseatpantoreleasetheseatfromthe
frame,thenslideittheoppositewaytoreleaseitfromtheotherside.
6.Lifttheseatassemblyoffofthemachine.
SeatInstallation(ZXModelsOnly)
1.Verifythatthefueltankholddownisseatedproperlyinthefrontandrearof
theframeandsecuredwiththeholddownbolt.
g321203
Figure28
2.Placetheseatontopofthefueltankandaligntheholeinonesideofthe
framewiththeholeintheseatplate.
3.Installthestoprodandsecurewithonecotterpin.
4.Slidetherodtowardtheoutsideofthemachinewhilealigningtheholeonthe
oppositesidewiththeholeintheframe.
5.Insertthestoprodtosecuretheseatinplaceandinstallthecotterpin.
6.Raisetheseatandconnectthewireharnessterminaltotheoperator
presenceswitch.
7.Liftandlowertheseattoverifyproperfunctionoftheseatpivotsandthe
seatlatch.
8.Connectthebatterybyinstallingthepositivecablerst,thenthenegative
cabletothebattery.
9.Verifyproperfunctionoftheunit.
Chassis:ServiceandRepairs
Page5–12
TitanServiceManual
3438-774RevA
