MowerSpindleDisassembly
g322066
Figure79
1.SpindleNut6.Spindle(ApplyAnti-Seize)
2.Pulley7.Blade
3.BearingShield
8.BellevilleWasher
4.SpindleMountingScrews
9.BladeBolt
5.SpindleAssembly
1.Clampthespindleforservicebyplacingthespindleshaftinavise.
2.Removethenutandwasherfromthetopofthepulley.
3.Removethepulley.
4.Removespindlehousingfromtheshaft.
5.Removethebearingshield.
6.Removethebearingandthebearingspacerfromthetopofthespindle
housing.
7.Flipoverthespindlehousingandremovethelowerbearing.
8.Inspecttheinsideofthespindlehousingforwearordamage.
MowerSpindleAssembly
1.Inspecttheinsideofthespindlehousingforwearordamage.
2.Pressthetopbearingintothespindlehousingbypressingequallyonthe
innerandouterrace.
Note:Ensurethatthebearingseatsagainsttheshoulderinthespindle
housing.
