ElectricPTOClutchInstallation
g322063
Figure82
1.EnginePulleytoShaft(ApplyAnti-Seize)4.ClutchIsolator
2.Bolt
5.PTOClutch
3.ClutchStopMount6.ClutchMountingBolt(ApplyLoctite)
1.Installtheclutchontothecrankshaftensuringthattheslotintheclutchaligns
withthetabontheclutchanchorandtherubberisolatorisinplace.
Note:Applyanti-seizetotheendofthepulleyshaft.
2.Applythreadlocktotheclutchbolt.
3.Installthewasherandclutchmountingbolt.T orquetheclutchboltto76±
7N•m(55±5ft-lb).
4.Connecttheclutchpowerwiretotheclutch.
Note:Ensurewireharnessisproperlyroutedtoavoidcontactwiththemower.
g322060
Figure83
MowerDeck:ServiceandRepairs
Page7–12
TitanServiceManual
3438-774RevA
