Toro Greensmaster eFlex 1800 User Manual

SamsungLithiumBatteryPack(forModels04042,04043,04046
and04049ttedwith04069)
CAUTION
TheeFlexSamsunglithiumbatterypackcontainshighvoltagewhich
couldburnorelectrocuteyou.
•Donotattempttoopenthebatterypack.
•Donotplaceanythingintheconnectorofthebatterypackother
thanthewireharnessconnectorthatcamewiththeproduct.
•Useextremecarewhenhandlingabatterypackwithacracked
case.
•Onlyusethechargerdesignedforthebatterypack.
Note:RefertoyourTractionUnitOperator’sManualandLithiumBatteryPack
ChargerOperator’sManualforadditionalinformationaboutSamsunglithium
batterypackserviceandhandling.
RemovingtheSamsungLithiumBatteryPack
1.Parkthemachineonalevelsurfaceandplacethetractionleverinthe
NEUTRALposition.TurnthekeyswitchtotheOFFpositionandremovethe
keyfromthekeyswitch.
2.Disconnectthebatterypack;refertoServiceProcedureIcons(page6).
Removethe8boltsthatsecuresthebatterycovertothemountbracket;refer
toFigure90.Removethebatterycoverfromthemountbracket.
g270009
Figure125
1.Positivebatterycable3.Negativebatterycable
2.Interfaceharnesscable
3.Removethepositivebatterycable,negativebatterycableandinterface
harnesscablefromthebattery;refertoFigure125.
ElectricalSystem:ServiceandRepairs
Page5–80
Greensmaster
®
eFlex1800,2100and2120
12189SLRevE

Toro Greensmaster eFlex 1800 Specifications

General

Cutting Width	18 inches
Power Source	Battery
Blade Type	Reel
Drive Type	Electric
Deck Type	Fixed
Warranty	2 years
Number of Blades	11-blade reel
