Toro Greensmaster eFlex 1800 User Manual

GroomerCover(CounterRotatingGroomerDrive)
OneFlexmachineswiththecounterrotatinggroomer,thegroomercover
includesahandlewhichengagesanddisengagesthegroomerdrive.Whenthe
handleisrotatedtowardthefrontofthemachine,thegroomerisengaged.
RemovingtheGroomerCover(CounterRotatingGroomerDrive)
1.Parkmachineonlevelsurface.TurnkeyswitchtotheOFFpositionand
removekeyfromtheswitch.EnsurethatthetractionleverisintheNEUTRAL
position.
2.Disconnectthebatterypack;refertoConnectingtheLithiumBatteryPack
(page8–3).
3.Ensurethatthehandleongroomercoverisrotatedtowardfrontofmachine
sothatthegroomerdriveisengaged.
g228144
Figure186
1.Groomercoverassembly3.Gasket
2.Flange-headscrew(5each)
4.Handle
4.Removegroomercoverassemblyfrommachine(Figure186):
A.Remove5ange-headscrewsthatsecuregroomercoverassemblyto
rightdriveplate.
B.Removegroomercoverassemblyandgasketfrommachine.Discard
gasket.
5.Ifnecessary,removeshaftfromgroomercover(Figure187):
A.Loosensetscrewontopofshaftandslidehandlefromshaft.
B.Removeretainingringandthrustwasherfromshaft.
C.Removeplungerdetentfromgroomercover.
D.Slideshaftoutofgroomercover.RemoveanddiscardO-ringfromshaft.
6.Removegreasefrominsidegroomercoverandrightdriveplateoncutting
unit.Thoroughlycleanandinspectallgroomerdrivecomponents.
Greensmaster
®
eFlex1800,2100and2120
Page8–7
BeltDrivenGroomer:ServiceandRepairs
12189SLRevE
