ServicingtheRoller
g206889
Figure170
1.Bearinglocknut4.Ballbearing
7.Rollershaft
2.V-ring
5.Wiehleroller
3.Seal6.Smoothroller
DisassemblingtheRoller
1.Toholdtherollershaft(item7inFigure170)forbearinglocknutremoval,
installa3/8-24UNF2Bscrewintothreadedendoftherollershaftandsecure
thescrewinplacewiththejamnut.Whileretainingtheshaft,removethe
bearinglocknutfromeachendoftherollershaft.
2.RemovetheV-ring(item2inFigure170)fromeachendoftheroller.
3.Carefullyinspecttheseatingsurfaceandthreadsofthebearinglocknuts
(item1inFigure170).Replacethelocknutifthereisanydamage.
4.Looselysecuretherollerassemblyinabenchviseandlightlytaponeend
oftherollershaftuntilthesealandbearingareremovedfromtheroller
cavity.Removethesecondsealandbearingfromtherollercavitybytapping
ontheshaft.
5.Cleanthebearingcavityintherollerandremoveanyrustwithcrocuscloth.
CuttingUnit:ServiceandRepairs
Page7–22
Greensmaster
®
eFlex1800,2100and2120
12189SLRevE
