InstallingtheBumper
ModelNo.31902Only
Partsneededforthisprocedure:
1Bumper
2
Bolt(3/8x2-3/4inches)
4
Bolt(3/8x3-1/4inches)
6
Nut(3/8inch)
Procedure
1.Removethebumperfromtheshippingskid.
2.Use4bolts(3/8x3-1/4inches)and4nuts(3/8
inch)tosecuretheupperareaofthebumperto
themachineframe(Figure14).
g302775
Figure14
1.Bolt(3/8x3-1/4inches)3.Bolt(3/8x2-3/4inches)
2.Bumper
3.Use2bolts(3/8x2-3/4inches)and2nuts(3/8
inch)tosecurethebumperunderthemachine
frame(Figure14).
10
ConnectingtheBattery
ModelNo.31902Only
NoPartsRequired
Procedure
Connectthebattery;refertoConnectingtheBattery
(page49).
