Pre-Maintenance
Procedures
RaisingtheMachine
DANGER
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseaserious
injury.
•Usejackstandstosupporttheraised
machine.
•Useonlymechanicalorhydraulicjacksto
liftthemachine.
RaisingtheFrontoftheMachine
Important:Ensurethatnocablesorhydraulic
componentsarebetweenthejackandtheframe.
g299729
Figure37
1.Frontjackingpoint—frame
tube
3.Frontofthemachine
2.Frontjackstand
point—frontaxletube
1.Chockthe2rearwheelswithchockstoprevent
themachinefrommoving.
2.Positionthejacksecurelyunderthedesired
jackingpoint.
3.Afterraisingthefrontofthemachine,usean
appropriatejackstandunderthemachineframe
tosupportthemachine.
40
