Togetmaximumpowerunderheavyloadorwhen
ascendingahill,havethethrottleintheFASTposition
whilepressingtractionpedalslightlytokeepthe
enginespeed(rpm)high.Iftheenginespeedbegins
todecreaserapidly,releasethetractionpedalslightly
toallowtheenginespeedtoincrease.
g219608
Figure19
1.Tilt-steeringlever2.Tractionpedal
Tilt-SteeringLever
Totiltthesteeringwheeltowardyou,pressthe
tilt-steeringlever(Figure19)downandpullthe
steeringtowertowardyou.Releasetheleverwhen
thesteeringtowerisatapositionthatallowsyouto
comfortablyhandlethesteeringwheel.
ParkingBrake
Wheneveryoushutofftheengine,engagethe
parkingbrake(Figure16)topreventthemachinefrom
accidentallymoving.
•Engagetheparkingbrake:Pullthehandleupto
theENGAGEDposition.
g219574
Figure20
1.DISENGAGEDposition2.ENGAGEDposition
•Disengagetheparkingbrake:Useyourthumb
topushdownthebuttononthetopofhandleand
lowerthehandledowntotheDISENGAGEDposition.
Note:Ifthehandleisnotcompletelylowered,the
machineshutsoffwhenyouengagethetraction
pedal.
Console
Refertothefollowingsectionsforadescriptionofthe
consolecontrols(Figure21).
g220213
Figure21
1.Displayscreenbutton
4.PTOswitch
2.Throttle-controlswitch5.Keyswitch
3.Attachmentliftswitch
6.Displayscreen
