Toro Groundsmaster 3310 Series - Installing the Front Tires; Installing the Tie-Down Bracket

5
InstallingtheFrontTires
ModelNo.31902Only
NoPartsRequired
Procedure
1.Usethepreviously-removedlugnutstosecure
thetirestothewheelhubs(Figure11).
g299550
Figure11
1.Wheelhub3.Lugnut
2.Tire
2.Torquethewheellugnuts;refertoT orquingthe
Wheel-LugNuts(page52)
6
InstallingtheTie-Down
Bracket
ModelNo.31902Only
Partsneededforthisprocedure:
1Tie-downbracket
2
Bolt(3/8x3-1/4inches)
2
Nut(3/8inch)
Procedure
Use2bolts(3/8x3-1/4inches)and2nuts(3/8inch)
tosecurethetie-downbrackettotheplatform(Figure
12).
g299562
Figure12
1.Tie-downbracket
3.Nut(3/8inch)
2.Bolt(3/8x3-1/4inches)
