Toro Groundsmaster 3310 Series - Cab Maintenance; Cleaning the Cab

CabMaintenance
CleaningtheCab
Important:Usecarearoundthecabseals(Figure
75).Ifyouareusingapressurewasher,keepthe
washerwandatleast0.6m(2ft)awayfromthe
machine.Donotusethepressurewasherdirectly
onthecabsealsorundertherearoverhang.
g303806
Figure75
1.Seal
3.Donotpressurewash
undertherearoverhang.
2.Keepwand0.6m(2ft)
away.
CleaningtheCabAirFilters
ServiceInterval:Every400hours
1.Removetheknobsandgratesfromthecabrear
overhang(Figure76).
g251432
Figure76
1.Filter
3.Grate
2.Knob
2.Removetheairltersfromthecab.
3.Cleantheltersbyblowingclean,oil-free,
compressedairthroughthem.
Important:Ifeitherlterhasahole,tear,or
otherdamage,replacethelter.
4.Usetheknobsandgratestoinstallthelters
intothecab(Figure76).
CleaningtheCab
CondenserFilter
Thepurposeofthecabcondenserlteristoprevent
largedebris,suchasgrassandleaves,fromentering
thecabcondenserandcondenserfans.
1.Pullthescreencoverstraightdown.
2.Cleanthecondenserlterwithwater.
Note:Donotuseapressurewasher.
Important:Ifthelterhasahole,tear,or
otherdamage,replacethelter.
3.Allowtheltertodrybeforeinstallingitintothe
machine.
4.Rotatethelterscreenaroundthetabsuntil
thelatchlocksintothelatch-mountassembly
(Figure77).
