InfoCenterIconDescriptions(cont'd.)
Right
Left
Bulb
OutputofTECcontrollerorcontrol
wireinharness
Switch
Operatormustreleaseswitch
Operatorshouldchangetoindicated
state
Symbolsareoftencombinedtoformsentences.Some
examplesareshownbelow.
Operatorshouldputmachinein
neutral
Enginestartisdenied
Engineshutdown
Enginecoolantistoohot
DPFashaccumulationnotication.
RefertoServicingtheDiesel
ParticulateFilter(DPF)inthe
maintenancesectionfordetails
Reset-standbyregenerationrequest
Parkedorrecoveryregeneration
request
Aparkedorrecoveryregenerationis
processing.
Highexhausttemperature
NOxcontroldiagnosismalfunction;
drivethemachinebacktotheshop
andcontactyourauthorizedT oro
distributor(softwareversionUand
later).
Thepowertake-offisdisabled.
InfoCenterIconDescriptions(cont'd.)
Sitdownorengagetheparking
brake.
Indicatesthatlimitedliftreverseis
active.
AccessibleonlybyenteringPIN
UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthe
menuaccessbuttonwhileatthemainscreen.This
displaysthemainmenu.Refertothefollowingtables
forasynopsisoftheoptionsavailablefromthemenus:
MainMenu
MenuItemDescription
Faults
Containsalistoftherecent
machinefaults.Referto
theServiceManualoryour
authorizedTorodistributorfor
moreinformationontheFaults
menuandtheinformation
containedthere.
DiagnosticsListsvariousstatesthatthe
machinecurrentlyhas;you
canusethistotroubleshoot
certainissuesasitquicklytells
youwhichmachinecontrols
areonandwhichareoff.
ServiceContainsinformationonthe
machinesuchashoursofuse,
counters,andothersimilar
numbers.
Settings
Allowsyoutocustomizeand
modifycongurationvariables
ontheInfoCenterdisplay.
AboutListsthemodelnumber,serial
number,andsoftwareversion
ofyourmachine.
Service
MenuItemDescription
Hours
Liststhetotalnumberofhours
thatthemachine,engine,and
PTOhavebeenon,aswell
asthenumberofhoursthe
machinehasbeentransported
andservicedue
Counts
Listsnumerouscountsthe
machineexperienced
DPFRegeneration
Thedieselparticulatelter
regenerationoptionandDPF
submenus
