Pre-Maintenance
Procedures
RaisingthePlatform
1.Movetheplatform-latchhandle(Figure42)
towardthefrontofthemachineuntilthelatch
hooksclearthelockingbar.
g290373
Figure42
1.Platform-latchhandle
2.Raisetheplatform(Figure43).
Note:Thegasliftcylinderassistsliftingthe
platform.
g290372
Figure43
LoweringthePlatform
WARNING
Operatingthemachinewiththeplatform
unlatchedmaycauseyoutolosecontrolof
themachine,resultinginseriousinjurytoyou
andbystanders.
Neveroperatethemachinewithoutrst
checkingthattheoperatorplatformlatching
mechanismisfullyengagedandingood
workingorder.
1.Lowertheplatformcarefully(Figure44).
Note:Thegasliftcylinderhelpssupportthe
platform.
g290371
Figure44
2.Astheplatformnearsthefullyloweredposition,
movetheplatform-latchhandle(Figure45)
towardthefrontofthemachine.
Note:Thisensuresthatthelatchhooksclear
thelockingbar.
g290369
Figure45
1.Platform-latchhandle
2.Lockingbar
