3.Fullylowertheplatformandmovethe

platform-latchhandletowardtherearofthe

machineuntilthelatchhooksfullyengagethe

lockingbar(Figure46).

g290370

Figure46

1.Platform-latchhandle

RemovingtheStorage

Compartment

1.Attheleftsideoftheoperator’splatform,open

thedoorofthestoragecompartment(Figure47).

g328513

Figure47

1.Washer

3.Storagecompartment

2.Knob

2.Removethe3knobsand3washersthatsecure

thestoragecompartmenttothemachine,and

removethecompartment(Figure47).

InstallingtheStorage

Compartment

1.Aligntheholesonthebottomofthestorage

compartmentwiththeholesinthechassis

brackets.

2.Assemblethestoragecompartmenttothe

machinewiththe3knobsand3washers(Figure

48)

g328512

Figure48

1.Washer

3.Storagecompartment

2.Knob

3.Closethestorage-compartmentdoor.
