ReplacingtheRemote
Batteries
Batteryspecication:AAA(1.5V)
Quantity:4
1.Removethe6screwssecuringthecoverhalves
ofthehandheldremotetogether,andremove
thebackcover(Figure41).
Note:Ifpossible,leavetherubbersealand
steelgasketinthechannelwhenremovingthe
coverandbatteries.
g341770
Figure41
1.Screw
5.AAAbatteries
2.Backcover6.Lanyardpin
3.Seal
7.Lanyardring
4.Steelgasket
8.Frontcover
2.Removethedischargedbatteriesandproperly
disposeinaccordancewithlocalregulations.
3.ObservingbatterypolarityasshowninFigure
42,insertthenewbatteriesintotheterminal
cradles.
Note:Wheninstallingbatteries,observeproper
polaritymarkings(Figure42)thatareembossed
ontothebatterycompartmenttoavoiddamaging
theterminalcradles.Youwillnotdamagethe
machineifyouincorrectlyinstallingthebatteries
inthehandheldremote,butthehandheldremote
willnotoperate.
g341771
g341769
Figure42
1.Positivebatterypolarity
4.Ensurethatthesteelgasketandrubbersealare
seatedinthechannelinthecoverhalfandalign
thebackcovertothefrontcover(Figure41).
5.Alignthelanyardringoverthelanyardpin
(Figure41).
6.Assemblethebackcovertotheandfrontcover
with6screws(Figure41).
7.Torquethescrewsto1.5to1.7N⋅m(13to15
in-lb).
