Figure31

Rearaxle

1.Greasetting(upperpivot)2.Greasetting(lowerpivot)

3.Wipeupanyexcessgrease.

GreasingtheDriveshaft

ServiceInterval:Every500hours

1.Cleanthegreasettingswitharag.

2.Connectthegreaseguntothegreasettingforthe

slidecouplingattheattheforwardendofthedrive

shaft,andapply2or3pumpsofgreasetothetting

(Figure32).

Figure32

1.Greasetting(forward

universaljoint)

3.Greasetting(back

universaljoint)

2.Greasetting(slidingjoint)

3.Connectthegreaseguntothegreasettingforthe

universaljointattheforwardendofthedriveshaft,

andapply2or3pumpsofgreasetothetting.

4.Connectthegreaseguntothegreasettingforthe

universaljointatthebackendofthedriveshaft,and

apply2or3pumpsofgreasetothetting.

5.Wipeupanyexcessgrease.

GreasingtheBackllBlade

ServiceInterval:Beforeeachuseordaily

1.Cleanthegreasettingswitharag.

2.Connectthegreaseguntotheupperandlowergrease

ttingsfortheliftcylinder,andapply3pumpsof

greasetoeachtting(Figure33).
