InfoCenterIconDescriptions(cont'd.)
Parkingbrake
Engine
Glowplugs
Engine-coolanttemperature
Enginespeed
Batteryvoltage
SmartLoadisactive.
Indicateswhenscheduled
serviceshouldbeperformed
DPFregenerationisrequired.
Aparkedorrecovery
regenerationisprocessing.
Highexhausttemperature
NOxcontroldiagnosis
malfunction;drivethemachine
backtotheshopandcontact
yourAuthorizedService
Dealer.
UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthe
menuaccessbuttonwhileatthemainscreen.
Thiswillbringyoutothemainmenu.Refertothe
followingtablesforasynopsisoftheoptionsavailable
fromthemenus:
MainMenu
MenuItemDescription
FaultsTheFaultsmenucontains
alistoftherecentmachine
andenginefaults.Referto
theServiceManualoryour
AuthorizedServiceDealerfor
moreinformationontheFaults
menuandtheinformation
containedthere.
ServiceTheServicemenucontains
informationonthemachine
suchashoursofuseandother
similarnumbers.
DiagnosticsTheDiagnosticsmenu
displaysthestateofeach
machineswitch,sensorand
controloutput.Youcanuse
thistotroubleshootcertain
issuesasitwillquicklytellyou
whichmachinecontrolsareon
andwhichareoff.
SettingsTheSettingsmenuallows
youtocustomizeandmodify
congurationvariablesonthe
InfoCenterdisplay.
AboutTheAboutmenuliststhe
modelnumber,serialnumber,
andsoftwareversionofyour
machine.
