Toro TX 1300 - Jump-Starting the Machine (Continued)

systemsareoffandatthesameratedsystem
voltage.Theseinstructionsarefornegative
groundsystemsonly.
4.Connectthepositive(+)cabletothepositive(+)
terminalofthedischargedbatterythatiswired
tothestarterorsolenoidasshowninFigure81.
g012785
Figure81
1.Positive(+)cableon
dischargedbattery
5.Boosterbattery
2.Positive(+)cableon
boosterbattery
6.Dischargedbattery
3.Negative(–)cableonthe
boosterbattery
7.Engineblock
4.Negative(–)cableonthe
engineblock
5.Connecttheotherendofthepositive(+)jumper
cabletothepositiveterminalofthebatteryin
theothermachine.
6.Connectanendofthenegative(-)jumpercable
tothenegativepostofthebatteryintheother
machine.
7.Connecttheotherendofthenegative(-)jumper
cabletoagroundpoint,suchasanunpainted
boltorchassismember.
8.Starttheengineintheothermachine.Letitrun
afewminutes,thenstartyourengine.
9.Removethecablesinthereverseorderof
connection.
10.Installthefrontcover.
